Used extensively at: -
Used for agricultural purposes, on construction sites, for damn projects, in bore wells, for removal of muddy water, fire fighting etc.
Used for agricultural purposes, on construction sites, for damn projects, in bore wells, for removal of muddy water, fire fighting etc.
Design Highlights / Features
- Light weight / Portable pump sets
- Come in Petrol, Kerosene and Diesel models
- Economical
- ISI Mark, Strong brand
- 4 Stroke, Air cooled engines
- Easy to maintain and service
- Available in high head, high discharge models
| Model | MK 12 Pumps Set | MK-25 Pumps set | 5520 | 5510 |
| Engine | Greaves Cotton Make | Greaves Cotton Make | Greaves Cotton Make | Greaves Cotton Make |
| Type | 4 stroke, Air cooled, Single Cylinder, Cylindrical Shaft | 4 stroke, Air cooled, Single Cylinder, Cylindrical Shaft | 4 stroke, Air cooled, Single Cylinder, Cylindrical Shaft | 4 stroke, Air cooled, Single Cylinder, Cylindrical Shaft |
| Horsepower | 2 HP | 3 HP | 5 HP | 8.3 HP |
| RPM | 3000 | 3000 | 3000 | 3000 |
| Pumps set weight | 33 kgs | 49 kgs | 55 kgs | 114 kgs |
| Pumps Size | 1" X 1" , 2" X 2" | 2" X 1.5" , 2.5" X 2" | 1" X 1" , 2" X 2" | 1" X 1" , 2" X 2" |
| Coupling Type | Monobloc | Monobloc | Monobloc and Coupled | Monobloc and Coupled |
| Head Range | 6 Meter to 21 Meter | 6 Meter to 27 Meter | 9 Meter to 45 Meter | 17 Meter to 52 Meter |
| Discharge Range | 120 LPM to 500 LPM | 300 LPM to 1100 LPM | 350 LPM to 2250 LPM | 300 LPM to 850 LPM |
| Irrigation Capacity | Up to 3 Acres | Up to 5 Acres | Up to 6 Acres | Up to 10 Acres |
| Ignition Capacity | Rope Start | Rope Start | Rope Start | Rope / Electric Start |
| Fuel | Petrol Start/ Kerosene Run | Petrol Start/ Kerosene Run | Diesel | Diesel |
| Tank Capacity | 2.75 Liters | 4.5 Liters | 4.5 Liters | 5.5 Liters |
Note : Models also available in 1500 RPM, 1800 RPM and 2600 RPM
Due to continuous changes towards product improvement, technical data is subject to change.
